Stroke 166.75 Closed 56.25 Rod Pin 2 Rod Width 2 Base Pin 2 LMSD 7 Stages 4 Stroke 166 Extended 405
Number of Stages 4
Largest Moving Stage Diameter 7 inches
Stroke Length (A) 166.06 in (4218 mm)
Closed Length (B) 56.25 in (1429 mm)
Extended Length (C) 222.31 in (5647 mm)
Rod Mount Width (D) 2 in (51 mm)
Rod Mount Pin Hole (E) 2.06 in (52 mm)
Base Mount Width (G) 8.63 in (219 mm)
Base Mount Pin Hole (J) 2.13 in (54 mm)
Port (L) 1" NPTF
Gallons of Oil (Retracted) 3.7
Gallons of Oil (Extended) 17.5
