Hydraulic Cylinder 53-892-84 Type Single Acting Telescopic Stroke 084.00 Closed 41.12 Rod Pin 1.63 Rod Width 1.5 Base Pin 2 LMSD 5 Stages 3 Stroke 84 Extended 170
The Hydraulic Cylinder 53-892-84 from HCIC is engineered as a direct OEM replacement for mobile equipment applications. Manufactured to ISO 9001:2015 standards, this cylinder matches original specifications for seamless drop-in installation.
Built with precision-machined components, hardened chrome-plated rod, and high-performance seals. Each unit is 100% pressure tested before shipment with a 12-month warranty.
Contact HCIC with your OEM part number for exact specifications and pricing.
| Part Number | 53-892-84 |
| Type | Double-Acting Hydraulic Cylinder |
| Working Pressure | 2,500 – 3,500 PSI |
| Mounting | Per OEM specifications |
| Seal Type | Heavy-duty polyurethane |
Hydraulic Cylinder 53-892-84
Number of Stages 3
Largest Moving Stage Diameter 5 inches
Stroke Length (A) 84.19 in (2138 mm)
Closed Length (B) 41.12 in (1044 mm)
Extended Length (C) 125.31 in (3183 mm)
Rod Mount Width (D) 1.5 in (38 mm)
Rod Mount Pin Hole (E) 2.06 in (52 mm)
Base Mount Width (G) 7 in (178 mm)
Base Mount Pin Hole (J) 2.06 in (52 mm)
Port (L) 3/4" NPTF
Gallons of Oil (Retracted) 1.7
Gallons of Oil (Extended) 6
