Industry Non-Classified Cylinder Type Single Acting Telescopic Stroke 155.75 Closed 52.63 Rod Pin 2 Rod Width 1.75 Base Pin 2 LMSD 6 Stages 4 Stroke 155 Extended 310
Cylinder Type Single Acting Telescopic Stroke 084.00 Closed 41.12 Rod Pin 1.63 Rod Width 1.5 Base Pin 2 LMSD 5 Stages 3 Stroke 84 Extended 170
Lift Cylinder for garbage truck
The Lift Cylinder can convert hydraulic energy into mechanical energy and perform straight movement. Its simple structure and stable work can bring more convenience to reduce the use of other foreign objects. Therefore, the hydraulic cylinder is widely used in various machinery.
All parameters can be customized
Parameters of the sample
Hydraulic Telescopic Cylinder for Tipping and Dumping HCIC has rich experience in hydraulic telescopic cylinder manufacturing. We have two main types for multi-stage cylinder: Dump Truck Hydraulic Telescopic Cylinder(FE, FEE, FC type) Dump Trailer Hydraulic Telescopic Cylinder(HTC type) We can also produce telescopic cylinder type as you need. Welcome contact us.
The structure of the telescopic hydraulic cylinder has a variety of structures, and there are many classification methods: according to the exercise method, it can be divided into a straight line movement and rotary swing type; according to the actual situation of liquid pressure, it can Forms can be divided into piston, plunger, multi -level telescopic sleeve type, gear rack type, etc.; according to the installation form, it can be divided into trolley, earrings, bottom, hinge shafts, etc.
Small Telescopic Hydraulic Cylinder
Weight:5
shaft diameter:80mm-245mm
Max Pressure:25MPa
Color:According to your requirements
Application:Dump truck,Tipper,Trailer
Package:Iron case, plywood case or carton box
Stroke:200mm-3000mm
Material:Steel
Structure:Telescopic Cylinder
Coating:chrome plated
