The 3TG-E90x1199 is a three-stage underbody telescopic hydraulic cylinder with a 1,199 mm stroke, 220 bar maximum working pressure and 5–14 ton catalog tipping range.
Review the catalog dimensions of the Model 520 hydraulic power hoist for dump trailer lifting systems and check frame space, mounting geometry and service clearance before a dump-trailer project.
The FE-4TG-E169*4280 front tipping hydraulic cylinder is listed for 49-ton dump-truck applications, with 16 MPa pressure and 1,345 mm closed length.
The Model 516 power hoist for dump trailer lifting systems is a compact lifting solution for dump trailers, with a 24-inch body dimension and 39.25-inch hoist length for installation planning.
The HCIC 6TG-E130x1947 underbody telescopic hydraulic cylinder for dump trailers has 6 stages, 1,947 mm stroke, 180 bar pressure and up to 11-18 ton tipping capacity.
The HCPGD double‑acting hydraulic power unit for dump trailers delivers 1.2 GPM flow, 3,000 PSI pressure and a 6-gallon tank for dump trailer hydraulic systems.
