Loader Bucket Hydraulic Cylinder Introduction： Maximum Stroke：9030mm Weight:：680, 680KG Suitable Excavator(ton):12ton, 12T Bucket type:Thumb bucket Materail:Q355B//NM400 Color:Customzied Loader Bucket Capacity/m3:0.48 Bucket capacity:0.48m³ Marketing Type:New Product 2022
Piston hydraulic cylinders come in two main structural types: single-rod and double-rod. When it comes to fixing methods, there are two common ways—either fixing the cylinder body itself or fixing the piston rod. In terms of hydraulic action, they’re divided into single-acting and double-acting types too.
For single-acting hydraulic cylinders, pressure oil is only supplied to one cavity of the cylinder. The extension or retraction of the cylinder is achieved by the pressure of this oil, while the return movement usually relies on external forces like the weight of the load or a spring. As for double-acting hydraulic cylinders, pressure oil alternates between the two cavities of the cylinder. This alternating oil supply pushes the piston to move in both directions, with the hydraulic pressure alone driving all the piston’s movements, no need for additional external forces. This design makes double-acting cylinders more flexible and widely used in scenarios that require precise control of both extension and retraction.
Do not operate with a load during the working process.
Common performance issues in such cases include inaccurate stopping of the piston rod, insufficient thrust, reduced speed, and unstable operation. The specific causes are as follows:
(1) Hydraulic oil is supposed to flow back to the oil tank through the relief valve during operation. If dirt enters the relief valve and jams its spool, keeping the relief valve in a normally open state, the hydraulic oil will directly flow back to the oil tank by bypassing the relief valve, resulting in no oil being supplied to the hydraulic cylinder. If the load is excessively heavy, even if the adjusted pressure of the relief valve has reached the maximum rated value, the hydraulic cylinder still cannot obtain the required thrust to maintain continuous operation and will fail to act. Additionally, if the adjusted pressure of the relief valve is too low, the system pressure will be insufficient to meet the thrust required by the load, which is specifically reflected in insufficient thrust. In such cases, it is necessary to check and adjust the relief valve in a timely manner.
All parameters can be customized
| The Specification of 7ton hydraulic cylinder | |||
|---|---|---|---|
| General | Model | FD70 | |
| Power Type | Diesel | ||
| Rated Capacity | kg 7000 | ||
| Load Centre | mm 600 | ||
| Characteristic&Dimension | Lift Height | mm 3000 | |
| Fork Size | L×W×T | mm 1220×150×70 | |
| Mast Tilt Angle | F/R | Deg 6°/12° | |
| Fork Overhang (Wheel center to fork face) | mm 595 | ||
| Ground Clearance (Bottom of mast) | mm 200 | ||
| Overall Dimension | Length to face of fork (Without fork) | mm 3565 | |
| Overall Width | mm 2010 | ||
| Mast Lowered Height | mm 2500 | ||
| Mast Extended Height (With backrest) | mm 4415 | ||
| Overhead Guard Height | mm 2430 | ||
| Turning Radius (outside) | mm 3350 | ||
| Speed | Travel (Full load) | km/h 30 | |
| Lifting (Full load) | mm/s 460 | ||
| Max.Gradeability | % 20 | ||
| Chassis | Tyre | Front | mm 8.25-15-14PR |
| Rear | mm 8.25-15-14PR | ||
| Wheelbase | mm 2250 | ||
| Self weight | kg 9750 | ||
| Power&Transmission | Battery | Voltage/Capacity | V/Ah (12/80) x 2 |
| Engine | Model | 6BG1-02 | |
| Manufacture | ISUZU | ||
| Rated output/r.p.m. | kw 82.4/2000 | ||
| Rated torque/r.p.m. | N·m 416/1600 | ||
| No.of Cylinder | 6 | ||
| Bore×Stroke | mm 105×125 | ||
| Displacement | cc 6494 | ||
| Fuel Tank Capacity | L 125 | ||
| Transmission | Type | Hydraulic | |
| Stage | FWD/RVS | 2/2 | |
Multiple hydraulic cylinders and single-beam crane telescopic arms often encounter a common issue: the hard chrome coating on the inner surface of the cylinder tends to peel off. This problem is mainly caused by three types of situations, each with clear causes and practical manifestations, as detailed below:
A. Poor adhesion of the hard chrome coating: This is usually because when processing the cylinder inner surface before electroplating, the oil removal and degreasing work is not done thoroughly—there may still be residual oil stains or dirt on the surface. In addition, if the surface activation treatment is not in place, the oxide film on the metal surface is not completely removed, which directly leads to poor adhesion between the chrome coating and the base metal, and finally causes the coating to peel off.
B. Wear and tear of the hard chrome layer: During the long-term use of the hydraulic cylinder, the piston moves back and forth inside the cylinder. The friction between the piston and the cylinder wall will generate iron powder, and these iron powder particles will act as an abrasive, constantly grinding the hard chrome coating on the inner surface. If there is water mixed in the hydraulic oil, the grinding effect will be more obvious, accelerating the wear of the chrome layer; in severe cases, the coating will be worn through, and even the base metal will be exposed.
C. Corrosion caused by contact potential difference: This kind of corrosion is not easy to occur when the hydraulic cylinder is in continuous operation, but it is very common when the cylinder is idle for a long time. Because when the cylinder is not working, the metal surfaces of different materials (such as the cylinder body and piston) are in contact, forming a potential difference, which leads to local corrosion. Especially when there is moisture or impurities in the hydraulic oil, the corrosion speed will be significantly accelerated, and the chrome coating will peel off due to corrosion damage.
Our team provides considerate service and assistance for overseas partners' hydraulic cylinder and hydraulic system projects, whether individual projects, OEM or ODM projects. We also provide a wide range of customized services to meet your project needs. We have been recognized as a reliable supplier of many international partners.
A variety of customized cylinder manufacturing, including single-stage cylinder (single-acting and double-acting), single-acting and double-acting telescopic (small and large aperture), double-head cylinder, back design, rolling mill cylinder, pull rod cylinder, accumulator, marine steering cylinder, stainless steel and standard size welding production line, etc. Why choose us? 1. 13years experience.
2. Perfect workmanship. Always committed to research and development.
3. Ensure the products meet the quality standards.
4. Ensure the goods will be delivered on time.
5. We will reply you within 2 hours.
6. Provide warm and friendly service and after-sale service.
7. Guaranteed the good quality and best service, as you buy from local supplier.
8. Assorted designs, colors, styles, patterns and sizes are available.
9. Customized specifications are welcome.
Q1. Can you help us design the hydraulic system for our machine?
A: Yes, our R&D team can provide full hydraulic system design, including cylinder selection, pump, valve, and piping layout, based on your machine requirements.
Q2.What is your warranty policy for hydraulic cylinders?
A: We offer a 12-month warranty. If any quality issue occurs within the warranty period, we will replace parts or cylinders free of charge, or provide a full refund
Q3. What are your packing conditions?
A: Usually, we pack the goods in neutral white boxes and brown cartons. If you have a legally registered patent, we can pack the goods in your brand packaging box after receiving your authorization letter.
Q4. How about your delivery time?
A: Generally speaking, it takes 30 to 60 days after receiving the advance payment. The specific delivery time depends onAccording to the item and quantity of your order.
Q5. Do you test all goods before shipment?
A: Yes, we conduct 100% test before delivery.
Q6: How do you maintain a long-term and good relationship with our business?
A: 1. We maintain good quality and competitive price to ensure the interests of customers;2. We regard every customer as our friend. We sincerely do business with them and make friends with them,No matter where they come from.
