Dimension(L*W*H):2880x2450x2700 Table Size (mm):1000x500 Number of Axes:5 Table Travel (X) (mm):800 Table Travel (Y) (mm):500 Table Travel (Z) (mm):500 Positioning Accuracy (mm):0.0075 Repeatability (X/Y/Z) (mm):0.005 Range of Spindle Speed(r.p.m):1 - 8000 r.p.m Spindle Motor Power(kW):7.5 Max. Table Load(kg):600 kg Min. Time of Tool Change(s):3
The milling machine refers to the milling machine used to process various surfaces of a workpiece. Generally, the milling cutter is mainly driven by rotary motion, and the workpiece and the milling cutter move as feed motion. It can be processed plane, groove, also can be processed a variety of curved surface, gear and so on.
High quality resin sand
Taiwan spindle
Taiwan ball screw and locking nut
Taiwan pressure cylinder
Japanese NSK bearing germany R+W coupling
Automatic lubrication system
Chip conveyor at optional
Application:
This VMC is suitable for mechanical processing and mold making .And it can asapt to the processing requirement from rough
machining to finish machining .It can also finish many working procedures like milling ,drilling ,tapping ,boring ,etc
All parameters can be customized
Parameters of the sample
| No. | Item | Specifications |
|---|---|---|
| A Technical parameters of machine tool: | ||
| 1 | The machine body and all parts are made of nano castings | |
| 2 | Table size | 500×400mm |
| 3 | T-groove (width x quantity x spacing) | 10×5×78mm |
| 4 | The largest load | 200KG |
| 5 | Maximum feed height | 280mm |
| 6 | Distance from spindle face to work | 100-280mm |
| 7 | Triaxial travel X/Y/Z | 450/400/170mm |
| 8 | The spindle diameter | Ø100mm |
| 9 | Spindle speed | 36000RPM |
| 10 | Spindle motor power | 6KW |
| 11 | Spindle tool library capacity | 8 |
| 12 | Tool change time | 5S |
| 13 | The spindle taper | ISO25 |
| 14 | Knife library classes | Servo disc rotation |
| 15 | Fast moving rate X/Y/Z | 12/12/12m/Min |
| 16 | Processing speed | 6－12m/Min |
| 17 | Positioning accuracy | ±0.006/300mm |
| 18 | Repetitive positioning accuracy | ±0.006/300mm |
| 19 | Machined surface accuracy | ≤Ra1.6 |
| 20 | The machining accuracy | ±0.01mm |
| 21 | Optional four-axis five-axis | Yes |
| 22 | Angle of rotation of axis A | ±105 degrees |
| 23 | Fifth axis C axis rotation Angle | 360 degrees |
| 24 | Five-axis linkage mode | 5 axis with the move |
| 25 | Working voltage | 380V/50HZ±10% or 220V/60HZ |
| 26 | Machine size (l * W * H) | 1450×1600×2100mm |
| 27 | The body weight | 1500KG |
| B Machine tool configuration details brand parameters: | ||
| 1 | The system configuration | Taiwan SYNTEC 6GA/Ncstudio280/LNC |
| 2 | The spindle | 6KW high-precision, high-speed, high-quiet oil-cooled spindle |
| 3 | Ball screw | Japan NSK, Germany RexRoth) 2005 |
| 4 | Linear guide | Taiwan HIWIN/ABBA high precision guide H25 |
| 5 | Servo unit | Panasonic Servo motor 750W/Ncstudio |
| 6 | Wire rod bearing | Taiwan TPI precision grade bearing |
| 7 | Switching power supply | Taiwan Ming weft |
| 8 | Electric switch | China chint |
| 9 | converter | * Square converter |
1.Gantry milling machine: including gantry milling and boring machine, gantry milling and planing machine and double column milling machine, are used for processing large parts.
2.Single column milling machine and single arm milling machine: the horizontal milling head of the former can move along the column guide rail, the table for longitudinal feed; The end milling head of the latter can move horizontally along the cantilever guide rail, and the cantilever can also adjust the height along the column guide rail. Both are used to process large parts.
3.table does not lift milling machine: there are two kinds of rectangular work table and round work table, is a medium size milling machine between lifting table milling machine and gantry milling machine. Its vertical movement is accomplished by lifting the milling head on the column.
4.Instrument milling machine: a small lifting table milling machine, used for processing instruments and other small parts.
5.Tool milling machine: Used for mold and tool manufacturing, equipped with vertical milling head, universal Angle table and plug and other accessories, but also for drilling, boring and interpolation machining.
6.Other milling machines: such as keyway milling machine, CAM milling machine, crankshaft milling machine, rolling journal milling machine and square ingot milling machine, etc., are special milling machines manufactured for processing the corresponding workpiece.
